Like most things in life, displays change, evolve and, happily, improve. As classic displays and control elements are increasingly being replaced by modern display stacks (Display Touch Cover lens or DTC), naturally new processes will come into play to bond the cover glasses or DTCs into their housings.
As the word ‘stack’ might suggest, various parts of these displays are bonded together. Firstly, the cover glass is bonded over its entire surface with a touch sensor using a transparent adhesive. The cover glass touch unit is then bonded to the display module using the same method.
Either a damping or structural adhesive can be used for the subsequent bonding of the display stack into a frame or housing. Of course, we must add a brief caveat here, as the overall process depends on several factors: the application area, material, DTC design and construction requirements. Because bonding a display stack isn’t always as straightforward as it might seem and there are plenty of considerations and challenges to be taken into account at every stage.
For example, the bonds must be resistant to moisture, grease, chemicals and UV rays. Then, additionally, each material expands and contracts at different rates and the chosen adhesive must be able to compensate for this. This means that judgements must be made in the early stages to decide which kind of bonding is the most appropriate. Simply – it’s all about the pros and cons.
| Double-sided tape bonding | |
|---|---|
| Pros | - ‘Easier’ bonding in the front frame - Fast further processing of the assembly (DTC + front frame) - Cost-effective solution |
| Cons | - Visible gap between front frame and cover glass - Dirt accumulation in the joint |
Okay, we admit it. Size does matter. At least it does when it comes to our new MIPI DSI displays. By popular demand, we’re upscaling your options with new 7” and 10.1” display kits, designed to fit seamlessly with STMicroelectronics’ STM32F769I and STM32H747I Discovery kits.
As you might imagine, we are very particular when it comes to who we partner with. After all, we have an impeccable track record for giving our customers the very best displays. So, we’d like to introduce you to Silicon Integrated Systems (SiS), whose specialized firmware and hardware meets our every expectation – and yours.
| Liquid adhesive bonding | |
|---|---|
| Pros | - Gap between front frame and cover glass is filled, which contributes to better sealing (protects against penetrating humidity) - Achievable protection class IP6X - Ensures better stability between frame and DCT - Enhance optics (less reflection leads to higher brightness and contrast) - Prevents glass splinters from flying around when the cover glass is destroyed |
| Cons | - The liquid adhesive takes longer to harden than the tape - The further processing of the assembly takes longer - High effort when dosing and positioning the parts |
Displays must withstand dust, rain, and snow without compromising performance. Our displays feature IP sealing with specialized tapes, glue or silicone to protect against environmental elements, ensuring reliability in any weather condition.
With ratings such as IP54, which offers splash-proof and dust-proof capabilities, and IP65, providing protection against water jets, manufacturers can ensure their products stand up to the elements. For the highest demands, IP67 guarantees dust-tight integrity and protection against 30 minutes immersion.
The use of liquid adhesive bonding effectively fills the gap between the front frame and cover glass, enhancing sealing performance. This method not only achieves an IP6X protection class but also demonstrates improved stability between the frame and DCT, making it essential for applications in demanding conditions.
|
|
